1. It is used to blowing LDPE, which has been widely used for producing, packing film, bag or film for textile and clothing and other packing material.
2. The main motor adopts inverter control of motor speed to improve the speed regulating stability of main motor and save electricity by 30%.
3. The screw and barrel adopt 38 chrome-molybdenum aluminum which has been nitrogen treated and the traction frame adopts lifting type. No matter what size the film is, big or small, it can achieve the best effect of cooling.
4.it can change roll automaticlly
Model | GBCA-600 | GBCE-1000 | GBCE-1200 | GBCE-1600 |
Screw diameter | 45mm | 55mm | 65mm | 75mm |
Screw length proportion(L/D) | 28:1 | 28:1 | 28:1 | 28:1 |
Film-blowing width | 100-600mm | 300-1000mm | 300-1200mm | 300-1600mm |
Film-blowing thickness | LDPE0.015-0.20mm HDPE0.008-0.05mm | |||
Output | 10-45kg/hour | 20-60kg/hour | 20-80kg/hour | 50-100kg/hour |
Main motor power | 11kw | 22kw | 37kw | 45kw |
Dimension of the machine | 5000×1500×4000mm | 5400×2800×4800mm | 5400×3000×6800mm | 6200×3400×7500mm |
Total weight | 3000kg | 3800kg | 4200kg | 4800kg |
