ABA multilayer blown film machine

  • The ABA multilayer blown film machine is combined with two extruders.
  • The ABA multilayer blown film machine is mostly used to reduce the raw material cost and improve the film strength
  • HDPE,LDPE,Bio material.
Output Range                         60-100kg/h
Screw size                               45mm,50mm,55mm
Film width                               600-1000mm
2 hours

Installed to
Production
15 years

Everage
lifetime
99.9%

Rate of
film pass

Applications

Plastic film this machine can produce.

Select Your Model

Items: GBCE-45x2
Max bag width: 600mm
Output one: 60kg/h
Main motor power: 11kw*2
Items: GBCE-50x2
Max bag width: 800mm
Output one: 80kg/h
Main motor power: 18.5kw*2
Items: GBCE-55x2
Max bag width: 1000mm
Output one: 100kg/h
Main motor power: 22kw*2

Specifications

Study more key configurations of this machine.
Model name ABA multilayer plastic film blowing machine, ABA blown film machine
Final product     HDPE, LDPE, LLDPE ,Bio-degradable Plastic Film compostable, corn starch
Thickness  0.01-0.1mm
Application  T-shirt bag, garbage bag, shopping bag ,flexible packaging bags,supermarket bag
Material   HDPE, LDPE, LLDPE ,BIO,recycled material, CaCO3 compound,  masterbatch and additives
Output range 60-100kg/h (depends on extruder size)
Optional device  Auto rewinder, auto loader,rotary die unit,double rewinder,corona treater,masterbatch dosing system,embossing roller
Delivery time  30-60days
Warranty 1 year
Technical assiatance  Engineers are available to service machine oversea

Video Show

Watch how the machine working in production.
The ABA multilayer blown film machine is mostly used to reduce the raw material cost and improve the film strength.
It also can blow Bio-degradable material, SILSTAR already made for customers.

Description

Read the complete introduction of machine and component pictures.
The ABA multilayer blown film machine is conbined with two extruders, For example, 55mm and 45mm screw for T-shirt bags film, while garbage bag film is usually use 55mm and 65mm screw.
The ABA multilayer blown film machine is mostly used to reduce the raw material cost and improve the film strength.
Our customers from some area like China Mainland, Vietnam, Thailand, Russia, have already updated with the ABA multilayer blown film machine from single screw extruder machine in order to keep themselves more competitive. Other areas in Turkey, Malaysia are always paying high attention to our ABA multilayer blown film machine.
Though Silstar’s main customers in Vietnam has purchased over 250 sets sigle screw film blowing machines and 20 sets ABA double screw blown film machines at the past 12 years, they still planning to update with ABA multilayer blown film machine continually, since the labour cost was grew significatly during these years. By the year of 2018, Silstar has already installed ABA multilayer blown film machine about 40 sets in Vietnam.
              Detail Pictures
