SILSTAR
| Quantity: | |
|---|---|
Model | GBCA-600 | GBCE-1000 | GBCE-1200 | GBCE-1600 |
Screw diameter | 45mm | 55mm | 65mm | 75mm |
Screw length proportion(L/D) | 28:1 | 28:1 | 28:1 | 28:1 |
Film-blowing width | 100-600mm | 300-1000mm | 300-1200mm | 300-1600mm |
Film-blowing thickness | LDPE0.015-0.20mm HDPE0.008-0.05mm | |||
Output | 10-45kg/hour | 20-60kg/hour | 20-80kg/hour | 50-100kg/hour |
Main motor power | 11kw | 22kw | 37kw | 45kw |
Dimension of the machine | 5000×1500×4000mm | 5400×2800×4800mm | 5400×3000×6800mm | 6200×3400×7500mm |
Total weight | 3000kg | 3800kg | 4200kg | 4800kg |
Model | GBCA-600 | GBCE-1000 | GBCE-1200 | GBCE-1600 |
Screw diameter | 45mm | 55mm | 65mm | 75mm |
Screw length proportion(L/D) | 28:1 | 28:1 | 28:1 | 28:1 |
Film-blowing width | 100-600mm | 300-1000mm | 300-1200mm | 300-1600mm |
Film-blowing thickness | LDPE0.015-0.20mm HDPE0.008-0.05mm | |||
Output | 10-45kg/hour | 20-60kg/hour | 20-80kg/hour | 50-100kg/hour |
Main motor power | 11kw | 22kw | 37kw | 45kw |
Dimension of the machine | 5000×1500×4000mm | 5400×2800×4800mm | 5400×3000×6800mm | 6200×3400×7500mm |
Total weight | 3000kg | 3800kg | 4200kg | 4800kg |
