HOME / PRODUCTS / Auxiliary Machine / 7-2-1 Plastic film side folding and forming machine

Folding and forming machine

  • DHL express/courier bag.
  • HDPE,LDPE
Speed                   70m/min
Fold width            200-900mm
2 hours

Installed to
Production
15 years

Everage
lifetime
99.9%

Rate of
film pass

Applications

Plastic bags this machine can produce.

Select Your Model

Items: GBZR-500
Forming  Width(mm): 200-500mm
Speed : 70m/min
Power: 1.5kw
Weight: 500kg
Items: GBZR-700
Forming  Width(mm): 200-700mm
Speed : 70m/min
Power: 1.8kw
Weight: 650kg
Items: GBZR-900
Forming  Width(mm): 200-900mm
Speed : 70m/min
Power: 2.5kw
Weight: 800kg

Specifications

Study more key configurations of this machine
Model name Side folding and forming machine
Final product        Folded film
Application  Express bags and self-sealing bags
Material  HDPE, LDPE, LLDPE , CaCO3 compound,  masterbatch and additives
Output range 70m/min
Delivery time 30-60days
Warranty 1 year
Technical assiatance Oversea Machine commissioning services are available.

Video Show

Watch how the machine working in production
This side folding and forming machine is used to fold films un-symmetrically while the film edge was being splited first on the blown film machine. Then the film would be re-rollled and get the length diversity on one side(folded un-symmetrically).

Description

Read the complete introduction of machine and component pictures.
This side folding and forming machine is used to fold films un-symmetrically while the film edge was being splited first on the blown film machine. Then the film would be re-rollled and get the length diversity on one side(folded un-symmetrically).
By using side seal hot cut bag making machine, the re-rolled film can be produced to express bags and self-sealing bags.
