Use:
This equipment is designed and manufactured on the basis of overseas advanced technology as well as domestic leading product of the same kind. As a fully automatic computer-controlled bag maker, it is mainly used to manufacture bags with films like PE, PP, PVC, etc.
Feature :
photoelectric controlled automatic feeding, photoelectric color-code follow-up, double or quadruple feeding, double or quadruple sealing, motor speed and bag length control by computer, automatic pile-up, etc., this machine is an ideal one to produce vest bag, flat-bottomed bag and fertilizer bag. ( Japan Panasonic Servo Motor and Servo Driver )
| Quantity: | |
|---|---|
bottom seal bag making machine is to produce the flat food bag piece by piece .
this one is semi-automatic bag making machine , if you need to produce t-shirt bag , also need one punching machine.
Model | GBD-500 | GBD-700 | GBD-900 |
Bag making width | 100-500mm | 100-700mm | 100-900mm |
Bag making length | 50-1200mm | 50-1200mm | 50-1200mm |
Bag making speed | 20-140bags/minute×4 | ||
Bag making thickness | 0.008-0.20mm | ||
The kinds of bag making | Color printing bags;white bags | ||
Bag making methods | Single sealing and single cutting;double sealing and single cutting | ||
Total power | 5kw | 6kw | 8kw |
Dimension of the machine | 3800×1100×1500mm | 3800×1300×1580mm | 3800×1500×1580mm |
